Technical sheet
| Printing Method | Thermal with fixed head |
| Number of dots | 8 dots/mm |
| Resolution | 203 DPI |
| Printing (mm/sec) | 140mm/sec |
| Character set | International (default), Chinese, Korean |
| Supported Barcode | UPCA, UPCE, EAN13, EAN8, CODE39, ITF, CODABAR, CODE93, CODE128, CODE32, PDF417, DATAMATRIX, AZTEC, QRCODE |
| Printing Format | Height and width from 1 to 8, bold, negative, underlined, script |
| Printing Direction | Straight, 90°, 180°, 270° |
| Paper width | 80 mm |
| Paper weight | from 58 to 80 g/m² |
| Paper thickness | from 63 to 80 μm |
| Roll Dimension | Ø 100 mm max |
| Emulation | CUSTOM/POS, PRT80, CUSTOM TPT |
| Interfaces | RS232 + USB |
| Data Buffer | 16 KB |
| Flash Memory | 1 MB internal, 4 MB external memory (1 MB of which is available to the user) |
| RAM Memory | 128Kb internal, 8MB external memory |
| Graphic Memory | 6 logos 608 x 215 |
| Drivers | Windows® (32/64 bit) – only on request WHQL and silent installation; Android™ |
| Software Tools | PrinterSet, CustomPowerTool, Status Monitor |
| Power supply | 24 Vdc ± 10% |
| Medium consumption | 1.2A (12,5% dots turned on) |
| MTBF | 122,000 hours (electronic board) |
| Head Life | 50 Km/100M pulses |
| Operating temperature | +0°C – +50°C |
| Dimensions | 210 (L) x 178.5 (H) x 136 (W) mm |
| Weight | 1.55 Kg |
